swivel castor with bolt hole, 50 mm

system number: HDHHHCC050P2T2P0N
  • galvanized and blue passivated sheet steel housing, pivot bearing with a double ball race, bolt hole fitting by bolt hole 11 mm, housing with material strength 1.5 mm (fitting) and 2.0 mm (fork), clearance between the fork individual, wheel rim made of polypropylene with a tread made of thermoplastic rubber (95 Shore A) grey colored, plain bearing, screwed wheel axle (incl. all axle material).
gentle to the ground,traceless
low start resistance
low roll resistance
versatile
temperature range from -20C to +60C

Technical specifications

payload
70 Kg
wheel diameter
50 mm
fastening
hole fitting 11 mm
total height
70 mm
Wheel width
19 mm
bearing surface
thermoplastic rubber 95 Shore A grey
Wheel center
polypropylene grey
hub width
44 mm
bearing
plain bearing
Axle screw
6 mm
